Brand | Keychron®︎ |
Price | high-class |
JIS/US | JIS, US |
Keyboard Size | 75% |
Key Profile | normal-profile |
Key Sounds | clicky, tactile, silent |
How to Connect | USB |
Battery | usb-power |
Hotswap | hotswap-available |
Normal or Split | 非分割 |
Comment
- Available from authorized distributors in Japan
- Probably the best 75% layout keyboard (operator subjective)
- A great machine that you can’t go wrong with purchasing.
- The V1 with ABS keycaps has a more pleasant keystroke sound.
- It is currently available in 12 colors, the most of any Keychron, and recently added a new color, ” Retro,” on May 31, 2023. The
Types of Keychron and how to choose ▷▷▷
The difference between Keychron Q1V1 and V2 is whether the keycap is ABS or PBT.
Hi, What’s the difference between the Q1 Knob version and Version 2?
– Keychron (@KeychronMK) November 28, 2022
# the keycaps. The Q1 original knob version uses the double shot ABS keycaps. Now version 2 Q1 use the double shot OSA PBT keycaps.
仕様詳細
- trade (brand) name
- Keychron Q1 (knob version)
- Total number of keys
- 85 keys (Japanese JIS)/81 keys (US)
- multimedia key
- 12 keys
- Frame Material
- CNC machined aluminum
- Plate material
- steel
- keycap
- Double-shot ABS(US),Dye-Sub PBT(JIS)
- MCU
- Ultra Low Power Arm Cortex-M4 32-bit STM32L432 (128KB Flash)
- backlight
- South-facing RGB LED
- switch
- Gateron G Pro (pre-assembled version)
- Supported hot swap
- Compatible with 3-pin or 5-pin MX style mechanical switches such as Gateron, Cherry MX and Kailh
- stabilizer
- Threaded PCB Stabilizer
- connection
- Type-C
- cable
- Type-C cable and Type-A to Type-C adapter
- Size
- 327.5 x 145mm x 35.8mm front height (22.6mm rear height excluding keycap)
- Weight (assembled)
- Approx. 1825 g ± 10 g (JIS), approx. 1970 g ± 10 g (US)
- contents
- Pre-assembled version: 1 Q1 keyboard (knob version) (keyboard includes: 1 aluminum case, 1 PCB, 1 steel plate, 1 sound-absorbing foam, 1 case foam, 16 gaskets (8 already installed), 4 sets of stabilizers, keycaps ( US is Double Shot ABS), Gateron G Pro switch x1set), Type-C to Type-C cable x1, Type-A to Type-C adapter x1, switch puller x1, keycap puller x1, screwdriver x1, hex wrench x1
Information reference: https: //kopek.jp/products/keychron-q1knob/
Selectable axis types
(Pre-Lubed)Gateron G Pro /Phantom Mechanical Switches
G Pro Red Switches | G Pro Blue Switches | G Pro Brown Switches | phantom Yellow Switches | |
pressing pressure | 45±15gf | 60±15gf | 55±15gf | 50±15gf |
Movement to operation | 2±0.6mm | 2.3±0.6mm | 2±0.6mm | 2±0.6mm |
keystroke | 4±0.6mm | 4±0.6mm | 4±0.6mm | 4±0.6mm |
reaction | linear | clicky | tactile | linear |
lubricating oil | ant | nashi (Pyrus pyrifolia, esp. var. culta) | ant | ant |
sound | quiet | clicky | gentle | quiet |
