| Brand | Keychron®︎ |
| Price | standard |
| JIS/US | JIS, US |
| Keyboard Size | 80%TKL |
| Key Profile | normal-profile |
| Key Sounds | clicky, tactile, silent |
| How to Connect | USB, Bluetooth |
| Battery | usb-power, rechargeable |
| Hotswap | hotswap-available |
| Normal or Split | 非分割 |
Comment
- February 20, 2024 Release
- To be handled by the Japanese distributor from December 2, 2024.
- English and Japanese layouts available
- Keychron V3 with two types of wireless connectivity in an 80% tenkeyless layout model
- Compared to the previous model, it has a wireless function and more sound-absorbing material, so you can expect a thockier typing sound.
- Gasket mount structure
- Compatible with QMK/VIA
- ABS plastic housing
- Keycap is double-shot PBT
- Keycap profiles are OEM profiles
- The price is $74.00 for the barebone model and $94.00 for the fully assembled model.
- Click here to purchase from the original official website ▷▷▷.
Where to Buy
- Keychron.com｜Official website with the entire product lineup
- Keychron on Amazon Official｜Amazon Japan’s official store
- Keychron (Rakuten Ichiba)
Types of Keychron and how to choose ▷▷▷
仕様詳細
We will add the details after the announcement.
Width | 140.56 mm |
|---|---|
| Length | 366.7 mm |
| Front Height | 22.04 mm (without keycaps) |
| Back Height | 30.05 mm (without keycaps) |
| Feet Height | 2 mm |
| Angle | 3.5° / 7.26° / 9.69 |
| Weight | 696 ± 10 g (Fully Assembled Version) |
| Body Material | ABS Plastic |
| Plate Material | PC |
| Keycaps (Fully Assembled Version) | Double-shot PBT keycaps, not shine-through, OSA Profile (OEM height, SA shape) |
| Switches | Gateron Jupiter (Fully Assembled Version) |
| Hot-swappable | Yes. Compatible with most of the 3 pin & 5 pin MX mechanical switches such as Gateron, Cherry MX, Kailh, etc. |
| Stabilizer | Screw-in PCB stabs |
| Cable | Type-C cable + Type-A to Type-C adapter |
| MCU | ARM Cortex-M4 32-bit STM32F402 (256KB Flash) |
| Charging Port | USB Type-C |
| Operating Environment | -10°C to 50°C |
| Polling Rate | 1000 Hz (2.4 GHz and wired) / 90 Hz (Bluetooth mode) |
| Mount Style | Gasket Mount Design |
| Backlight | South-facing RGB LED |
| N-Key Rollover (NKRO) | Yes for both wireless and wired modes |
| Compatible System | Windows/macOS/Linux |
| Bluetooth Version | 5.1 |
| Bluetooth Device Name | Keychron V3 Max |
| Battery | 4000 mAh Rechargeable li-polymer battery |
| Charging Time | Around 5 hours |
| Wireless Working Time (Backlit off) | Up to 225 hours (Lab test results may vary by actual use) |
| Wireless Working Time (RGB) | Up to 100 hours (Lowest brightness) |
Information reference: https: //www.keychron.com/products/keychron-v3-max-qmk-via-wireless-custom-mechanical-keyboard
Selectable axis types
The keyswitches available are Gateron Jupiter red, brown, and banana axes.
Gateron Jupiter Switches
| Switch | Red | Brown | Banana |
|---|---|---|---|
| Picture. |  |  |  |
| Feel | Linear | Tactile | Tactile Like Panda Feel |
| Color | Red | Brown | Yellow |
| Lubed. | Pre-Lubed | Pre-Lubed | Pre-Lubed |
| Operating force | 45±15gf | 55±15gf | 59±10gf |
| Pre-Travel | 2.6±0.6mm | 2.6±0.6mm | 2.6±0.6mm |
| Total Travel | 4.0mm MAX | 4.0mm MAX | 3.4mm MAX |
