Keychron Q1 Max

2024年8月31日

当ページのリンクには広告が含まれています。

このキーボードの概要

Comment

December 12, 2023 Release
Priced at $189.00 for the barebone model and $209.00 for the fully assembled model
Available in carbon black and shell white
The keycaps have a new color and are the latest KSA profile.
Keycaps will be made of PBT material
Screw-in stabilizers are used.
The keyswitch is a new Gateron Jupiter switch.
Two wireless connection methods: 2.4GHz using a USB dongle and Bluetooth 5.1
In the 2.4 GHz band, the polling rate is 1000 Hz.
The wired connection method is USB Type-C as before.
In addition to the gasket-mounted construction, premium acoustic foams such as IXPE, PET, and Latex have greatly improved the keystroke feel.
Compatible with QMK/VIA
Hot-swappable
Crowdfunding for the JIS array model will begin on April 11, 2024 on Makuake.
The Japanese layout model has ABS keycaps and a different coloring, but the Makuake model is the first to use double-shot PBT. (Makuake｜Keychron Q1 Max JIS Rayout Model)
Click here to purchase ▷▷▷.

あわせて読みたい

Keychron Q1 Max 日本語レイアウトがMakuakeに登場 2024年4月11日、日本のクラウドファウンディングサイト「Makuake（マクアケ）」にて、Keychron Q1 Max 日本語配列のクラウドファウンディングが開始されました。 https:…

Difference between Keychron Q/Q Pro /Q Max

	Q Max	Q Pro	q
Connection method	USB Type-C 2.4GHz Bluetooth 5.1	USB Type-C Bluetooth 5.1	USB Type-C
Polling rate (2.4GHz band)	1000Hz	90Hz	long vowel mark (usually only used in katakana)
QMK/VIA compatible	support	support	support
key switch	Gateron Jupiter	Keychron K Pro	Gateron G Pro
Sound-absorbing foam	5 layers	two layers	two layers
mount	Gasket mount	Gasket mount	Gasket mount
hot swap	support	support	support
keycap	Double-shot PBT	Double-shot PBT	ABS /PBT
profile	KSA Profile	KSA Profile	OEM Profile

このキーボードのキー配列・サイズは【JIS, US】【75%】です。

Where to Buy

仕様詳細

Width	145 mm
Length	327.5 mm
Front Height	22.6 mm (without keycaps)
Back Height	35.8 mm (without keycaps)
Feet Height	2.4 mm
Angle	5.2°
Weight	1724 g ± 10 g (Fully Assembled version)
Body Material	Aluminum
Plate Material	PC
Keycap.	KSA double-shot PBT keycaps, not shine-through (Fully assembled version)
Switch	Gateron Jupiter (Fully Assembled version)
Stabilizer	Screw-in PCB stabilizer
Backlight	South-facing RGB LED
Hot-swappable	Yes. Compatible with most of the 3 pin & 5 pin MX mechanical switches such as Gateron, Cherry MX and Kailh, etc.
MCU	ARM Cortex-M4 32-bit STM32F402 (256KB Flash)
Polling Rate	1000 Hz (2.4 GHz & wired) / 90 Hz (Bluetooth)
N-Key Rollover (NKRO)	Yes for both wireless and wired modes
Battery	4000 mAh Rechargeable li-polymer battery
Wireless Working Time (Backlit off)	Up to 180 hours (Lab test results may vary by actual use)
Wireless Working Time (RGB)	Up to 100 hours (Lowest brightness)
Bluetooth Version	5.1
Compatible System	macOS/Windows/Linux
Connectivity	2.4 GHz / Bluetooth / Type-C wired
Bluetooth Device Name	Keychron Q1 Max
Operating Environment	-10 to 50°C

Information reference: Keychron.com

タップできる目次

[blog_parts id="41919"]

Selectable axis types

There are three axes to choose from: Gateron Jupiter’s red, brown, and banana axes.

Gateron Jupiter Switches

Switch	Red	Brown	Banana
Picture.
Feel	Linear	Tactile	Tactile Like Panda Feel
Color	Red	Brown	Yellow
Lubed.	Pre-Lubed	Pre-Lubed	Pre-Lubed
Operating force	45±15gf	55±15gf	59±10gf
Pre-Travel	2.6±0.6mm	2.6±0.6mm	2.6±0.6mm
Total Travel	4.0mm MAX	4.0mm MAX	3.4mm MAX
