このキーボードの概要
| Brand | Keychron®︎ |
| Price | high-class |
| JIS/US | US |
| Keyboard Size | 96%Full |
| Key Profile | normal-profile |
| Key Sounds | Choose what you like |
| How to Connect | Bluetooth, USB |
| Battery | usb-power, rechargeable |
| Hotswap | hotswap-available |
| Normal or Split | 非分割 |
Comment
- Launched on March 26, 2024
- Price: $219.00 (full version) / $199.00 (barebone version)
- Mechanical keyboard with 96% layout with numeric keypad on left side
- Looks like a Q1 with a Q0 number pad attached.
- Available in two color schemes: carbon black and shell white
- Gateron Jupiter series key switches are used.
- Compared to the previous Pro, the polling rate for 2.4 GHz wireless connections has been updated to 1000 Hz.
- Also, expect thockier keystrokes with more sound-absorbing material than the Pro model.
- Gasket-mounted structure for soft keystroke feel
- Keycaps have KSA profile and are much taller than Cherry
- Supports QMK/VIA and allows keymap changes
- Hot-swappable and replaceable keyswitches
Where to Buy
- Keychron.com｜Official website with the entire product lineup
- Keychron on Amazon Official｜Amazon Japan’s official store
- Keychron (Rakuten Ichiba)
Types of Keychron and how to choose ▷▷▷
仕様詳細
| Width | 145 mm |
|---|---|
| Length | 409.4 mm |
| Front Height | 20.2 mm (without keycaps) |
| Back Height | 30.9 mm (without keycaps) |
| Feet Height | 2.4 mm |
| Angle | 5.2° |
| Weight | 2195 g ± 10 g (Fully Assembled version) |
| Body Material | Aluminum |
| Plate Material | PC |
| Keycap. | KSA double-shot PBT keycaps, not shine-through (Fully assembled version) |
| Switch | Gateron Jupiter (Fully Assembled version) |
| Stabilizer | Screw-in PCB stabilizer |
| Backlight | South-facing RGB LED |
| MCU | ARM Cortex-M4 32-bit STM32F402 (256KB Flash) |
| Battery | 4000 mAh Rechargeable li-polymer battery |
| Wireless Working Time (Backlit off) | Up to 180 hours (Lab test results may vary by actual use) |
| Wireless Working Time (RGB) | Up to 100 hours (Lowest brightness) |
| Bluetooth Version | 5.1 |
| Hot-swappable | Yes. Compatible with most of the 3 pin & 5 pin MX mechanical switches such as Gateron, Cherry MX and Kailh, etc. |
| Compatible System | macOS/Windows/Linux |
| Polling Rate | 1000 Hz (2.4 GHz & wired) / 90 Hz (Bluetooth) |
| N-Key Rollover (NKRO) | Yes for both wireless and wired modes |
| Connectivity | 2.4 GHz / Bluetooth / Type-C wired |
| Bluetooth Device Name | Keychron Q12 Max |
| Operating Environment | -10 to 50°C |
Information reference:.
タップできる目次
[blog_parts id="41919"]
Selectable axis types
Gateron Jupiter Switches
| Switch | Red | Brown | Banana |
|---|---|---|---|
| Picture. |  |  |  |
| Feel | Linear | Tactile | Tactile Like Panda Feel |
| Color | Red | Brown | Yellow |
| Lubed. | Pre-Lubed | Pre-Lubed | Pre-Lubed |
| Operating force | 45±15gf | 55±15gf | 59±10gf |
| Pre-Travel | 2.6±0.6mm | 2.6±0.6mm | 2.6±0.6mm |
| Total Travel | 4.0mm MAX | 4.0mm MAX | 3.4mm MAX |
