| Brand | Keychron®︎ |
| Price | high-class |
| JIS/US | US |
| Keyboard Size | 65% |
| Key Profile | normal-profile |
| Key Sounds | clicky, tactile, silent |
| How to Connect | Bluetooth, USB |
| Battery | usb-power, rechargeable |
| Hotswap | hotswap-available |
| Normal or Split | 非分割 |
Comment
- January 30, 2024 Release
- Top of the line Keychron Q8 series
- Ultra-low latency with a polling rate of 1000 Hz in the 2.4 GHz band using a USB dongle
- Equipped with keycaps with KSA profile
- Supports two types of wired/wireless connections (triple mode supported)
- Color lineup includes carbon black and shell white
- Priced at $219.00 for the full assembly model and $199.00 for the barebone model
- Compatible with QMK/VIA
- Hot-swappable
- Double gasket construction and multiple layers of sound-absorbing foam for soft keystroke feel
- Click here to purchase
Where to Buy
- Keychron.com｜Official website with the entire product lineup
- Keychron on Amazon Official｜Amazon Japan’s official store
- Keychron (Rakuten Ichiba)
Types of Keychron and how to choose ▷▷▷
仕様詳細
| Width | 136.15 mm |
| Length | 358.09 mm |
| Height without keycap (front) | 20.69 mm |
| Height without keycap (rear) | 32.47 mm |
| Height incl. keycap (front) | 34.84 mm |
| Height incl. keycap (rear) | 47.65 mm |
| Feet Height | 2.7 mm |
| Angle | 5°. |
| Weight | 1745± 10 g (Fully Assembled version) |
| Body Material | aluminum (Aluminum) |
| Plate Material | PC |
| Keycap. | KSA double-shot PBT keycaps, not shine-through (Fully assembled version) |
| Switch | Gateron Jupiter (Fully Assembled version) |
| Stabilizer | Screw-in PCB stabilizer |
| Backlight | South-facing RGB LED |
| Hot-swappable | Yes. Compatible with most of the 3 pin & 5 pin MX mechanical switches such as Gateron, Cherry MX and Kailh, etc. |
| MCU | ARM Cortex-M4 32-bit STM32F402 (256KB Flash) |
| Polling Rate | 1000 Hz (2.4 GHz & wired) / 90 Hz (Bluetooth) |
| N-Key Rollover (NKRO) | Yes for both wireless and wired modes |
| Operating Environment | -10 to 50°C |
| Battery | 4000 mAh Rechargeable li-polymer battery |
| Wirelwss Working Time (Backlit off) | Up to 180 hours (Lab test results may vary by actual use) |
| Wireless Working Time (RGB) | Up to 100 hours (Lowest brightness) |
| Bluetooth Version | 5.1 |
| Compatible System | macOS/Windows/Linux |
| Connectivity | 2.4GHz / Bluetooth / Type-C wired |
| Bluetooth Device Name | Keychron Q8 Max |
Information reference: https: //www.keychron.com/products/keychron-q8-max-alice-layout-qmk-via-wireless-custom-mechanical-keyboard?variant= 40822895837273
Selectable axis types
There are three types of axes that can be selected: Gateron Jupiter switches.
Gateron Jupiter Switches
| Switch | Red | Brown | Banana |
|---|---|---|---|
| Picture. |  |  |  |
| Feel | Linear | Tactile | Tactile Like Panda Feel |
| Color | Red | Brown | Yellow |
| Lubed. | Pre-Lubed | Pre-Lubed | Pre-Lubed |
| Operating force | 45±15gf | 55±15gf | 59±10gf |
| Pre-Travel | 2.6±0.6mm | 2.6±0.6mm | 2.6±0.6mm |
| Total Travel | 4.0mm MAX | 4.0mm MAX | 3.4mm MAX |
