Keychron V5 Max

2024年8月31日

当ページのリンクには広告が含まれています。

このキーボードの概要

Comment

December 25, 2023 Release
Priced at $79.00 for the barebone model and $99.00 for the fully assembled model
Available in carbon black only
Keycaps will be the same coloring as before and will be OSA profile.
Keycaps will be made of PBT material
Screw-in stabilizers are used.
The keyswitch is a new Gateron Jupiter switch.
Two wireless connection methods: 2.4GHz using a USB dongle and Bluetooth 5.1
In the 2.4 GHz band, the polling rate is 1000 Hz.
The wired connection method is USB Type-C as before.
Gasket-mounted construction for soft keystroke feel. (Normal model is top-mounted)

There is more sound-absorbing material than before, with sound-absorbing foam, PET foam, and case foam from top to bottom. The silicone pads on the bottom appear to have been changed.
Compatible with QMK/VIA
Hot-swappable
Click here to purchase ▷▷▷.

Difference between Keychron V /V Max

	V1 Max	V1
Connection method	USB Type-C 2.4GHz Bluetooth 5.1	USB Type-C
plate (often as in “tectonic plate”)	PC (Polycarbonate)	steel
Mounting Method	Gasket mount	Tray Mount
MCU Storage	256KB	128KB

	V Max	V
Connection method	USB Type-C 2.4GHz Bluetooth 5.1	USB Type-C
plate (often as in “tectonic plate”)	polycarbonate	steel
Mounting Method	Gasket mount	Top mount
MCU Storage	256KB	128KB
Polling rate (2.4GHz band)	1000Hz	long vowel mark (usually only used in katakana)
QMK/VIA compatible	support	support
key switch	Gateron Jupiter	Gateron G Pro
Sound-absorbing foam	three layers	two layers
mount	Gasket mount	Gasket mount
hot swap	support	support
keycap	Double-shot PBT	Double-shot PBT
profile	OSA Profile	OSA Profile

Where to Buy

このキーボードのキー配列・サイズは【US】【96%Full】です。

仕様詳細

Width	148.7 mm
Length	328.5 mm
Front Height	21.5 mm (without keycaps)
Back Height	29.4 mm (without keycaps)
Feet Height	2 mm
Angle	3.5° / 7.1° / 9.5
Weight	925 ± 10g (Fully Assembled Version)
Body Material	ABS Plastic
Plate Material	PC
Polling Rate	1000 Hz (2.4 GHz and wired) / 90 Hz (Bluetooth mode)
Mount Style	Gasket Mount Design
Bluetooth Device Name	Keychron V5 Max
Battery	4000 mAh Rechargeable li-polymer battery
Wireless Working Time (Backlit off)	Up to 225 hours (Lab test results may vary by actual use)
Wireless Working Time (RGB)	Up to 100 hours (Lowest brightness)
Charging Time	Around 5 hours
Bluetooth Version	5.1
Compatible System	Windows/macOS/Linux
N-Key Rollover (NKRO)	Yes for both wireless and wired modes
Hot-swappable	Yes. Compatible with most of the 3 pin & 5 pin MX mechanical switches such as Gateron, Cherry MX, Kailh, etc.
Keycaps (Fully Assembled Version)	Double-shot PBT keycaps, not shine-through, OSA Profile (OEM height, SA shape)
MCU	ARM Cortex-M4 32-bit STM32F402 (256KB Flash)
Switches	Gateron Jupiter (Fully Assembled Version)
Backlight	South-facing RGB LED
Stabilizer	Screw-in PCB stabs
Charging Port	USB Type-C
Cable	Type-C cable + Type-A to Type-C adapter
Operating Environment	-10°C to 50°C

Information reference: Keychron.com

タップできる目次

[blog_parts id="41919"]

Selectable axis types

There are three axes to choose from: Gateron Jupiter’s red, brown, and banana axes.

Gateron Jupiter Switches

Switch	Red	Brown	Banana
Picture.
Feel	Linear	Tactile	Tactile Like Panda Feel
Color	Red	Brown	Yellow
Lubed.	Pre-Lubed	Pre-Lubed	Pre-Lubed
Operating force	45±15gf	55±15gf	59±10gf
Pre-Travel	2.6±0.6mm	2.6±0.6mm	2.6±0.6mm
Total Travel	4.0mm MAX	4.0mm MAX	3.4mm MAX
