このキーボードの概要
| Brand | Keychron®︎ |
| Price | standard |
| JIS/US | JIS, US |
| Keyboard Size | 100%Full |
| Key Profile | normal-profile |
| Key Sounds | Choose what you like |
| How to Connect | Bluetooth, USB |
| Battery | usb-power, rechargeable |
| Hotswap | hotswap-available |
| Normal or Split | 非分割 |
Comment
- September 5, 2024 Release
- 100% layout mechanical keyboard with CherryMX compatible key switches.
- Compared to the previous Pro, it has been updated with a new polling rate of 1000 Hz for 2.4 GHz connections and more sound absorbing materials.
- Only hot-swappable and RGB backlit models are available, and only key switches are selectable
- Key switches can be selected from three types of Keychron Super Red/Super Brown/Super Banana
- Key maps can be changed using the Keychron Launcher web app
- Replacement keycaps for both Windows and Mac included
- Thocky keystroke feel can be expected due to the use of multilayer acoustic foams such as IXPE, PET, and EPDM
- Triple-mode USB Type-C wired/2.4GHz wireless/BT connection
- Changeable between Windows and Mac with physical buttons
- Supports hot-swapping
- Keycaps are OSA profile, material is PBT and double-shot, so there is no need to worry about the legend disappearing.
- Threaded PCB stabilizer is used.
- South facing RGB mounted
- Tilt angle can be changed up to 3 levels
- Click here to purchase ▷▷▷.
Keychron K10 Max QMK Mac英語配列 有線 / Bluetooth 5.1 / 2.4GHz ワイヤレス両対応 テンキー付き ホットスワップ Keychron Super スイッチ バナナ軸 WHITE LEDライト PBTダブルショットキーキャップ カスタムメカニカルキーボード キークロン
Where to Buy
- Keychron.com｜Official website with the entire product lineup
- Keychron on Amazon Official｜Amazon Japan’s official store
- Keychron (Rakuten Ichiba)
Types of Keychron and how to choose ▷▷▷
仕様詳細
| Number of Keys | 108 (100%) |
|---|---|
| Switches | Keychron Super mechanical |
| Switch Face | South-facing |
| Number of Multimedia Keys | 12 |
| Frame Material | ABS |
| Keycap Material | Double-shot PBT |
| Keycap Profile | OSA (OEM profile with spherical-angle) |
| Layout | ANSI |
| Polling Rate (2.4GHz and Wired Mode) | 1000Hz |
| Polling Rate (BT Mode) | 90Hz |
| N-Key Rollover (NKRO) | Yes for both wireless and wired modes |
| Backlit | 22 types of RGB backlight options plus endless possibilities |
| Battery | 4000 mAh rechargeable li-polymer battery |
| Wireless Working Time (Backlit off) | Up to 146 hours (Lab test results may vary by actual use) |
| Wireless Working Time (RGB) | Up to 121 hours (Lowest brightness) |
| Connection | 2.4 GHz / Bluetooth / Type-C wired |
| Bluetooth version | 5.1 |
| Bluetooth Device Name | Keychron K10 Max |
| Compatible System | macOS / Windows / Linux |
| Dimension | 447.37mm x 139.82mm (17.61 x 5.50″) |
| Weight | 1530g / 3.37 lbs |
| Height without keycap (front) | 23.7 mm (0.93″) |
| Height without keycap (rear) | 29.8 mm (1.17″) |
| Height incl. keycap (front) | 32.9 mm (1.29″) |
| Height incl. keycap (rear) | 40.1mm (1.57″) |
| Typing Angle | 3.43º, 7.26º and 10.06º |
| MCU | ARM Cortex-M4 32-bit STM32F402 (256KB Flash) |
| Operating Environment | -10 to 50°C |
Information reference: https: //www.keychron.com/products/keychron-k10-max-qmk-wireless-mechanical-keyboard
タップできる目次
About the keyswitch to be adopted
Keychron Super Switch
| Features | Red | Brown | Banana |
|---|---|---|---|
| Operating force | 45 ±15 gf | 55 ±15 gf | 47 ±8 gf |
| Pre-travel | 2.0 ±0.4 mm | 2.0 ±0.4 mm | 2.0 ±0.4 mm |
| Travel distance | 4.0 ±0.4 mm | 4.0 ±0.4 mm | 3.6 ±0.4 mm |
| Behavior | Linear | Tactile | Tactile (Similar to Panda switches) |
| Pre-lubed | Yes | Yes | Yes |
| Sound level | Quiet | Gentle | Gentle |
| Suitable for | Office/gaming | Midway Office/gaming | Office/gaming |
| Spring length | Double-stage 19 mm | Single-stage 15.2 mm | Double-stage 21.5 mm |
