Keychron K13 Pro

2024年8月31日

当ページのリンクには広告が含まれています。

このキーボードの概要

Comment

April 25, 2023 Release
Price: $94.00 (White BAcklight)-$104.00 (RGB Backlight)
Based on an 80% array, it has a numeric keypad and directional keys. This irregular model is not equipped with special keys.
Mechanical keyboard with low-profile keyswitches
Since it bears the Pro designation, it is QMK/VIA compliant and allows for keymap changes.
Equipped with aluminum frame, but no sound absorption mechanism
Newly designed stabilizers are used.
Three-step tilting leg
The only “Pro” in the lineup with no “unbranded” model
Since the price is the same as that of the upwardly compatible K13 Max, K13 Max is recommended if you want to purchase one.

Selectable types

Selectable switches

Where to Buy

あわせて読みたい

Keychron K13 Max QMK/VIA Wireless Custom Mechanical Keyboard 80％+α
メカニカル方式（Low-Profile）
US

このキーボードのキー配列・サイズは【US】【80%TKL】です。

User Manual: Keychron K13 Pro User Guide

仕様詳細

Number of Keys: 87 (80%)
Switches: Gateron low-profile mechanical
Switch Face: North-facing
Number of Multimedia Keys: 12
Frame Material: ABS+Aluminum frame
Keycap Material: Low-profile double-shot PBT
Layout: ANSI
Polling Rate (Wired Mode): 1000Hz
Polling Rate (Wireless Mode): 90Hz
N-Key Rollover (NKRO): Yes for both wireless and wired modes
Backlit: 22 types of RGB backlight options plus endless possibilities
Battery: 2000 mAh rechargeable li-polymer battery
BT Working Time (Backlit off): Up to 100 hours (Lab test results may vary by actual use)
BT Working Time (RGB): Up to 33 hours (Lowest brightness)
Connection: Bluetooth and Type-C cable
Bluetooth version: 5.1
Bluetooth Device Name: Keychron K13 Pro
Compatible System: macOS/Windows/Linux
Dimension: 346 x 118.5 mm (13.62 x 4.66″)
Weight: 580 g / 1.28 lbs
Height without keycap (front): 7.72 mm (0.3″)
Height without keycap (rear): 14.7 mm (0.58″)
Height incl. keycap (front): 18.2 mm (0.72″)
Height incl. keycap (rear): 24.1 mm (0.95″)
Typing Angle: 0º, 6º and 9º
MCU: Ultra-low-power ARM Cortex-M4 32-bit STM32L432 (128KB Flash)
Operating Environment: -10 to 50°C

タップできる目次

[blog_parts id="41919"]

Selectable key switches

*The blue axis cannot be selected.

Gateron Low-profile Switches 2.0 (Gateron Official)

Switch	Red	Brown	Blue	Banana
Picture.
Feel	Linear	Tactile	Clicky.	Tactile
Color	Red	Brown	Blue	Yellow
Lubed.	Pre-Lubed	Pre-Lubed	Pre-Lubed	Pre-Lubed
Pressure	50gf	55gf	65gf	60gf
Operating force	50±15gf	55±15gf	65±15gf	60±15gf
End force	60±5gf	60±5gf	70±5gf	unknown
Spring	13.5mm	13.5mm	11.5mm	unknown
Pre-Travel	1.7±0.4mm	1.7±0.4mm	1.7±0.4mm	1.7±0.4mm
Total Travel	3.2±0.2mm	3.2±0.2mm	3.2±0.2mm	3.2±0.2mm
