このキーボードの概要
| Brand | Keychron®︎ |
| Price | standard |
| JIS/US | US |
| Keyboard Size | 100%Full |
| Key Profile | normal-profile |
| Key Sounds | clicky, tactile, silent |
| How to Connect | USB |
| Battery | usb-power |
| Hotswap | hotswap-available |
| Normal or Split | 非分割 |
Comment
- February 27, 2024 Launch
- Price: $99.00 (full version) ~ / $79.00 (barebone version)
- Available in carbon black only
- Supports triple mode of connection method: BT connection, 2.4GHz USB dongle connection, and Type-C wired
- 1000 Hz wireless connection in the 2.4 GHz band
- Gasket-mounted structure and sound-absorbing foam improve key feel and sound when compared to previous models.
- Keycaps are OSA profile with PBT double shot
- QMK/VIA support allows keymap changes
- Click here to purchase ▷▷▷.
Where to Buy
- Keychron.com｜Official website with the entire product lineup
- Keychron on Amazon Official｜Amazon Japan’s official store
- Keychron (Rakuten Ichiba)
Types of Keychron and how to choose ▷▷▷
仕様詳細
| Width | 149.0 mm |
|---|---|
| Length | 447.9 mm |
| Front Height | 22.6 mm (without keycaps) |
| Back Height | 30.3 mm (without keycaps) |
| Feet Height | 2 mm |
| Angle | 3.5° / 7.0° / 9.5 |
| Weight | 1110 ± 10 g (Fully Assembled Version) |
| Body Material | ABS Plastic |
| Plate Material | PC |
| Polling Rate | 1000 Hz (2.4 GHz and wired) / 90 Hz (Bluetooth mode) |
| Mount Style | Gasket Mount Design |
| Battery | 4000 mAh Rechargeable li-polymer battery |
| Wireless Working Time (Backlit off) | Up to 225 hours (Lab test results may vary by actual use) |
| Wireless Working Time (RGB) | Up to 100 hours (Lowest brightness) |
| Charging Time | Around 5 hours |
| Bluetooth Version | 5.1 |
| Compatible System | Windows/macOS/Linux |
| N-Key Rollover (NKRO) | Yes for both wireless and wired modes |
| Hot-swappable | Yes. Compatible with most of the 3 pin & 5 pin MX mechanical switches such as Gateron, Cherry MX, Kailh, etc. |
| Keycaps (Fully Assembled Version) | Double-shot PBT keycaps, not shine-through, OSA Profile (OEM height, SA shape) |
| Switches | Gateron Jupiter (Fully Assembled Version) |
| MCU | ARM Cortex-M4 32-bit STM32F402 (256KB Flash) |
| Backlight | South-facing RGB LED |
| Stabilizer | Screw-in PCB stabs |
| Charging Port | USB Type-C |
| Cable | Type-C cable + Type-A to Type-C adapter |
| Bluetooth Device Name | Keychron V6 Max |
| Operating Environment | -10°C to 50°C |
Information reference: https: //www.keychron.com/products/keychron-v6-max-qmk-via-wireless-custom-mechanical-keyboard?variant=40912031711321
タップできる目次
Selectable axis types
Gateron Jupiter Switches
| Switch | Red | Brown | Banana |
|---|---|---|---|
| Picture. |  |  |  |
| Feel | Linear | Tactile | Tactile Like Panda Feel |
| Color | Red | Brown | Yellow |
| Lubed. | Pre-Lubed | Pre-Lubed | Pre-Lubed |
| Operating force | 45±15gf | 55±15gf | 59±10gf |
| Pre-Travel | 2.6±0.6mm | 2.6±0.6mm | 2.6±0.6mm |
| Total Travel | 4.0mm MAX | 4.0mm MAX | 3.4mm MAX |
