このキーボードの概要
| Brand | Keychron®︎ |
| Price | high-class |
| JIS/US | US |
| Keyboard Size | 75% |
| Key Profile | low-profile |
| Key Sounds | Choose what you like |
| How to Connect | Bluetooth, USB |
| Battery | usb-power, rechargeable |
| Hotswap | hotswap-available |
| Normal or Split | 非分割 |
Comment
- August 22, 2023 Release
- 75% layout version of Keychron K11Pro
- It is a low-profile key switch, which makes it very thin.
- Supports wired/wireless connection (wireless function is not available in Japan due to lack of technical qualification at the time of release)
- Rotary encoder knob is mounted in the upper left corner.
- Keycaps are made of double-shot PBT
- Newly designed stabilizers are used
- Equipped with tilt leg
- Priced at $94.00 for the White Backlight model and $104.00 for the RGB Backlight model
- Compatible with QMK/VIA
- Hot-swappable
- Click here to purchase
Where to Buy
- Keychron.com｜Official website with the entire product lineup
- Keychron on Amazon Official｜Amazon Japan’s official store
- Keychron (Rakuten Ichiba)
Types of Keychron and how to choose ▷▷▷
仕様詳細
| Number of Keys | 89 (75%) |
| Switches | Gateron low-profile mechanical |
| Switch Face | North-facing |
| Number of Multimedia Keys | 12 |
| Frame Material | ABS+Aluminum frame |
| Keycap Material | Low-profile double-shot PBT |
| Layout | ANSI |
| Polling Rate (Wired Mode) | 1000Hz |
| Polling Rate (Wireless Mode) | 90Hz |
| N-Key Rollover (NKRO) | Yes for both wireless and wired modes |
| Backlit | 22 types of RGB backlight options plus endless possibilities |
| Battery | 2000 mAh rechargeable li-polymer battery |
| BT Working Time (Backlit off) | Up to 515 hours (Lab test results may vary by actual use) |
| BT Working Time (RGB) | Up to 21 hours (Lowest brightness) |
| Connection | Bluetooth and Type-C cable |
| Bluetooth version | 5.1 |
| Bluetooth Device Name | Keychron K15 Pro |
| Compatible System | macOS/Windows/Linux |
| Dimension | 370 x 143 mm (14.57 x 5.63″) |
| Weight | 696 g / 1.53 lbs |
| Height without keycap (front) | 11.5 mm (0.45″) |
| Height without keycap (rear) | 16.5 mm (0.65″) |
| Height incl. keycap (front) | 21.3 mm (0.84″) |
| Height incl. keycap (rear) | 29 mm (1.14″) |
| Typing Angle | 2.7º, 3.9º and 6.1º |
| MCU | Ultra-low-power ARM Cortex-M4 32-bit STM32L432 (128KB Flash) |
| Operating Environment | -10 to 50°C |
*The K15 Pro is currently compatible with Gateron/Keychron low-profile mechanical switches only, as QMK does NOT support low-profile optical switches .
Information reference: https: //www.keychron.com/products/keychron-k15-pro-alice-layout-qmk-via-wireless-custom-mechanical-keyboard
タップできる目次
[blog_parts id="41919"]
Selectable axis types
The axes available for selection are Gateron LowProfile 2.0 Red/Brown/Blue.
Gateron Low-profile Switches 2.0 (Gateron Official)
| Switch | Red | Brown | Blue | Banana |
|---|---|---|---|---|
| Picture. |  |  |  |  |
| Feel | Linear | Tactile | Clicky. | Tactile |
| Color | Red | Brown | Blue | Yellow |
| Lubed. | Pre-Lubed | Pre-Lubed | Pre-Lubed | Pre-Lubed |
| Pressure | 50gf | 55gf | 65gf | 60gf |
| Operating force | 50±15gf | 55±15gf | 65±15gf | 60±15gf |
| End force | 60±5gf | 60±5gf | 70±5gf | unknown |
| Spring | 13.5mm | 13.5mm | 11.5mm | unknown |
| Pre-Travel | 1.7±0.4mm | 1.7±0.4mm | 1.7±0.4mm | 1.7±0.4mm |
| Total Travel | 3.2±0.2mm | 3.2±0.2mm | 3.2±0.2mm | 3.2±0.2mm |
